2.54mm Pitch SMD Wire To Board Connector 90 Degree DIP Type For PCB

  • 1
  • 2

Brand Name : XTKCONN

Model Number : Wafer housing terminal

Certification : CE,SGS,ROHS,ISO9001

Place of Origin : Guangdong,China

MOQ : 1000pcs

Price : Negotiable price

Payment Terms : L/C, T/T,Payyal

Supply Ability : 3KK pcs

Delivery Time : 5-7 days

Packaging Details : inner package:in reel; Outer Package: reel in Carton

Name : Wafer Connector

Pitch : 2.54mm

Type : DIP type

Insulator Color : Beige

OEM/ODM : Accepted

Packing : Reel Packing

Contact Now

Smd Wire To Board Connector 2.54mm Pitch Connector 90 Degree DIP Type For PCB





Product Description



Pitch 2.54mm
Mounting Type SMT
No. Of Positions 2-15p
Rated current 3.0A AC DC
Rated voltage 250V AC/DC
Contact Resistance 20m ohms MAX
Insulation Resistance 1000m ohms min
Insertion Force 20gf/pin Min
Operation Temperature -25℃ to +85℃
Withstanding Voltage 1000V/1min AC
Housing LCP,PA6T UL94V-0
Contact Brass Tin-plated
Gender Female
Price Term FOB
Durability cycles 5000 Cycles Min
Lead Time 7-10 working Days
Wire AWG #22-28

2.54mm Pitch SMD Wire To Board Connector 90 Degree DIP Type For PCB



Drawing



2.54mm Pitch SMD Wire To Board Connector 90 Degree DIP Type For PCB



Other Pitch

Pitch 1.25mm 2.00mm 2.50mm 2.54mm 3.96mm 4.20mm
Current Rating 1 Ampere 2 Ampere 3 Ampere 3 Ampere 7 Ampere 5-9 Ampere
Contact Resistance(Max) 20m ohm 20m ohm 20m ohm 20m ohm 20m ohm 20m ohm
Withstand Voltage for one minute 500 V AC 500 V AC 500 V AC 500 V AC 500 V AC 500 V AC
Insulator Resistance(Min) 100 M ohm 100 M ohm 100 M ohm 100 M ohm 100 M ohm 100 M ohm





Application



Our products are widely used in a variety of markets and applications, including:
Telecom and datacom systems and equipment
Computers, peripherals, systems
Industrial controls and robotics
Instrumentation
Medical
Test and Measurement
Automotive
Avionic and Military




Main Export Markets



Asia
Australia
Central/South America
Mid East/Africa
North America
